Paper shredder
- 【Production capacity】： 0.6-8t/h
- 【Discharge particle size】： The size is determined by the number of knife claws
- 【Power】： 15kw-160kw
- 【Applicable materials】： Carton, paper tube, paper core, book paper, document paper, kraft paper, cardboard...
【Keyword】：
- Waste paper box crusher
- waste pipe crushing and processing equipment
Product Introduction
The waste paper shredder is specially developed for the waste paper recycling and processing industry, mainly used for crushing cardboard boxes, paper tubes, book paper, etc. to reduce their size, increase their packing density, facilitate transportation and subsequent processing. This device is widely used in waste paper packaging stations, packaging enterprises, and paper mills. The waste paper shredder has the characteristics of low speed, high torque, and low noise. It adopts a PLC control system and can be automatically controlled. It is equipped with start, stop, reverse, and overload automatic reverse control functions.
The crushing process is mainly completed by the principle of "cutting and tearing". The electric motor drives the reducer to transmit torque to the moving knife through the knife roller shaft. The knife hook of the moving knife hooks the material and tears it down. The blades of the roller chop the material like scissors, and the crushed material is discharged from the bottom.
Performance characteristics:
1. Ultra low speed, super high torque, 8-30 revolutions per minute.
2. Low noise and low dust.
3. Optional motor or hydraulic motor.
4. Customers can freely choose between integral shredding blades or assembled detachable blades based on the different properties of the materials.
5. Use advanced simulation software to ensure the mechanical structure of integral or combined blades and avoid fracture and disassembly.
6. Optional hydraulic forced feeding device can shred materials more efficiently and quickly.
7. The double locking structure at both ends of the shaft head ensures the installation position of the blade and prevents axial displacement.
8. Adopting microcomputer (PLC) automatic control, with functions of start, stop, reverse and overload automatic reverse control.
9. Conduct a feeding test 80-100 hours before leaving the factory to ensure equipment reliability.
Product advantages
The maximum feed size can reach 2800 millimeters, and the discharge particle size can be controlled within the range of 3-30 millimeters according to demand
can efficiently process various solid wastes such as metal, plastic, rubber, wood, etc
able to meet the industrial processing needs of different scales, crush materials, reduce volume, and lower subsequent transportation and processing costs
The hydraulic system can adjust the tool spacing to meet the crushing requirements of materials with different hardness or characteristics
working principle
The shredder independently drives two main shafts to rotate forward and backward through dual motors. The moving blades on the main shafts interlock to form shear, the cutting edge of the moving blade forms shear with the cylindrical surface of the blade sleeve, and the torque and speed difference of the main shaft form tearing to achieve the crushing effect. Due to the interlocking of the moving blades, automatic feeding function can be achieved. The unique blade shaft structure ensures that there will be no entanglement or equipment jamming during low-speed and high torque production processes, thereby improving production efficiency. The core working principle of the shredder is based on the interaction between the dual axis or single axis rotating blade rollers. The surface of the knife roller is equipped with high-strength cutting tools, which are driven by a low-speed high torque motor to continuously shear the material. The arrangement of cutting tools (such as staggered or spiral) directly affects the crushing effect, while the spacing between the cutting rollers determines the particle size of the discharged material. The main body of the equipment adopts a metal frame structure, equipped with wear-resistant lining plates and dust-proof sealing devices to adapt to high-intensity working environments. Some models also integrate a hydraulic drive system, which can automatically adjust the inlet pressure to avoid material jamming problems.
Surgical parameters
|
型号
|
刀具规格
|
减速机
|
功率
|
|---|---|---|---|
|
500型
|
220×20
|
ZQ400
|
22kw
|
|
600型
|
300×30
|
ZQD650
|
60kw
|
|
800型
|
400×40
|
ZQD650
|
74kw
|
|
1000型
|
400×40
|
ZQD750
|
90kw
|
|
1200型
|
580×53
|
ZSSH315
|
110kw
|
|
1500型
|
600×60
|
ZSSH400
|
180kw
|
|
2000型
|
800×80
|
ZSSH500
|
260kw
|
