Waste furniture shredder
- 【Production capacity】： 0.6-8t/h
- 【Discharge particle size】： The size is determined by the number of knife claws
- 【Power】： 15kw-160kw
- 【Applicable materials】：Used toy cars, used sofas, used mattresses...
- 【】：
【Keyword】：
- Waste sofa crushing and processing equipment
- Equipment for crushing and processing waste mattresses
- Equipment for crushing and processing waste toys
Product Introduction
The waste furniture shredder is a core equipment designed specifically for processing large waste materials, mainly used for crushing and reducing the volume of large garbage such as waste furniture, sofas, tables and chairs, mattresses, etc. This equipment reduces the size of materials through crushing, shredding, and other methods, facilitating subsequent transportation, sorting, and resource utilization. It is one of the key equipment for modern urban solid waste disposal and the construction of a "waste free city".
The processing capacity of the waste furniture shredder is between 10 and 60 cubic meters per hour, and the discharge size is usually within the range of 100 to 300 millimeters, which is uniformly controllable.
On site, different models of double or four axis shredders can be selected according to the composition, size, production requirements, and discharge particle size requirements of the materials to be processed.
The waste furniture shredder, with its efficient capacity reduction, intelligent operation and maintenance, durable and reliable mechanical structure, and promoting resource recycling, has become an important technical equipment for solving the problem of large garbage disposal and promoting the resource utilization of solid waste.
Application scope:
Living furniture: mattresses, doors and windows, cabinets, tables and chairs, sofas, etc
Garbage: household waste, medical waste, kitchen waste, industrial waste, garden waste
Bucket products: plastic buckets, metal buckets, paint buckets, IBC buckets, garbage cans
Plastic products: plastic bottles, plastic frames, plastic blocks, plastic cans
Metal products: aluminum profiles, oil filters, car casings, cans, metal cans, steel wire ropes
Electronic appliances: refrigerators, circuit boards, laptop cases, TV cases, CD discs. Glass products: glass wool, glass cups, glass bottles
Product advantages
The maximum feed size can reach 2800 millimeters, and the discharge particle size can be controlled within the range of 3-30 millimeters according to demand
can efficiently process various solid wastes such as metal, plastic, rubber, wood, etc
able to meet the industrial processing needs of different scales, crush materials, reduce volume, and lower subsequent transportation and processing costs
The hydraulic system can adjust the tool spacing to meet the crushing requirements of materials with different hardness or characteristics
working principle
The shredder independently drives two main shafts to rotate forward and backward through dual motors. The moving blades on the main shafts interlock to form shear, the cutting edge of the moving blade forms shear with the cylindrical surface of the blade sleeve, and the torque and speed difference of the main shaft form tearing to achieve the crushing effect. Due to the interlocking of the moving blades, automatic feeding function can be achieved. The unique blade shaft structure ensures that there will be no entanglement or equipment jamming during low-speed and high torque production processes, thereby improving production efficiency. The core working principle of the shredder is based on the interaction between the dual axis or single axis rotating blade rollers. The surface of the knife roller is equipped with high-strength cutting tools, which are driven by a low-speed high torque motor to continuously shear the material. The arrangement of cutting tools (such as staggered or spiral) directly affects the crushing effect, while the spacing between the cutting rollers determines the particle size of the discharged material. The main body of the equipment adopts a metal frame structure, equipped with wear-resistant lining plates and dust-proof sealing devices to adapt to high-intensity working environments. Some models also integrate a hydraulic drive system, which can automatically adjust the inlet pressure to avoid material jamming problems.
Surgical parameters
|
型号
|
刀具规格
|
减速机
|
功率
|
|---|---|---|---|
|
500型
|
220×20
|
ZQ400
|
22kw
|
|
600型
|
300×30
|
ZQD650
|
60kw
|
|
800型
|
400×40
|
ZQD650
|
74kw
|
|
1000型
|
400×40
|
ZQD750
|
90kw
|
|
1200型
|
580×53
|
ZSSH315
|
110kw
|
|
1500型
|
600×60
|
ZSSH400
|
180kw
|
|
2000型
|
800×80
|
ZSSH500
|
260kw
|
